Acoustic Consultation Room Doors
High-Performance Sound Isolation for Hospital Privacy & Patient Confidentiality
Ensure complete acoustic privacy and peace of mind in healthcare environments with TCR Doors' acoustic consultation room doors. Engineered for consultation offices, examination rooms and sensitive diagnostic suites, these solid soundproof doors block unwanted noise transfer to maintain doctor-patient confidentiality.
Manufactured with heavy-duty steel framing and high-density solid acoustic cores, our flush systems deliver strong Sound Transmission Class (STC) performance, structural durability and hygienic finishes — with acoustic performance covered by our steel-door CE documentation (EN 14351-1) and further acoustic test data available on request.
Why Clinics Specify TCR Acoustic Doors
Real acoustic engineering. Multi-layer solid cores, perimeter gaskets and automatic drop seals — not just a heavier leaf.
Privacy by design. Solid flush construction, no glass, no louvers — 100% visual privacy.
Documented performance. STC rating and acoustic test documentation available for specification sheets.
Factory-direct flexibility. Sizes, finishes and hardware per your schedule — OEM/ODM, FOB/CIF.
Key Features & Benefits
Superior soundproofing. Solid multi-layer acoustic core with perimeter drop-seals effectively eliminates sound leakage between corridor and room (STC 35–45+, custom levels available).
100% visual privacy. Solid flush leaf with no vision panels or louvers ensures maximum confidentiality for sensitive examinations and counseling.
Hygienic and easy to clean. Smooth, non-porous powder-coated or stainless surfaces withstand frequent hospital-grade disinfection.
Heavy-duty durability. CNC-fabricated steel construction resists high-frequency usage, impact and daily wear in busy clinic corridors.
Hermetic acoustic perimeter. Heavy-duty rubber gaskets and automatic bottom drop-seals block both sound transmission and drafts.
STC Selection Guide
Rating Typical application STC 35 General consultation & exam rooms STC 40 Psychological counseling, social work offices STC 45+ Audiology adjacencies, psychiatric consults, executive suites Technical Specifications
Parameter Specification Acoustic rating STC 35 – STC 45+ (custom soundproofing levels available) Door design Solid flush leaf (no glass / no louvers) Leaf thickness 45–55 mm high-density solid acoustic composite core Steel sheet thickness Leaf 0.8–1.2 mm / frame 1.2–2.0 mm galvanized steel Acoustic seals Heavy-duty perimeter gaskets & automatic drop-down bottom seal Surface finish Antibacterial powder coating (RAL colors) / satin stainless steel Hardware Silent-latching mortise locks, heavy-duty hinges, automatic closers Configurations Single / double / equal & unequal leaf assemblies Ideal Applications
Consultation & examination suites: protect private doctor-patient discussions and sensitive results. Executive & admin offices: quiet, confidential workspaces. Psychiatric & therapy rooms: calm, secure sound-isolated environments. Audiology & testing facilities: minimal corridor noise during diagnostics.
Customization & OEM/ODM Supply
We provide complete OEM/ODM solutions tailored to your project dimensions, wall opening specs and acoustic requirements — CAD drawings, acoustic documentation and factory-direct pricing. Contact our technical engineering team for a quotation.
FAQ
Q: Which STC level should we specify?
A: STC 35 suits general consults; STC 40-45 for counseling, psychiatric or audiology adjacencies. Share room adjacencies and we'll recommend a level.Q: Do you have acoustic test reports?
A: Yes — our steel doors carry EN 14351-1 CE documentation covering acoustic performance, and project-specific acoustic data can be provided for specification sheets.Q: Does the drop seal need power?
A: No — automatic drop seals are mechanically actuated by the leaf itself as it closes.Q: Can we add vision panels later if protocols change?
A: Acoustic builds are solid by design; glazed acoustic variants can be specified at order stage if monitoring is required.Q: How does it perform against fire codes?
A: Fire-rated acoustic combinations are available — specify the required rating (e.g., A1.0) with your STC target.
