Double-Acting Traffic Doors
+
  • Double-Acting Traffic Doors
  • Double-Acting Traffic Doors

Double-Acting Traffic Doors

Heavy-duty double-acting impact traffic doors for hospitals, kitchens & warehouses. Self-centering gravity hinges, wash-down faces. Get a quote!
  • Product details
  • Double-Acting Traffic Doors

    High-Durability Impact Doors for Continuous, Hands-Free Traffic

    Streamline workflow and maintain temperature control with TCR Doors' double-acting traffic doors. Engineered for busy commercial, industrial and hospital facilities, these impact-resistant doors swing open smoothly in both directions on contact and return automatically to center — keeping carts, trolleys and staff moving without doors left ajar.

    Built with high-density composite cores, reinforced steel frames and heavy-duty gravity hinges in our Shanghai plant, they withstand constant impact from push carts, hospital beds and motorized equipment — day after day, shift after shift.

    Why Facility Managers Choose TCR Traffic Doors

    • Built for impact, not just look. Reinforced leaf construction absorbs continuous cart contact without warping.

    • Self-centering reliability. Top-and-bottom gravity hinges with V-cam mechanisms close accurately every cycle.

    • Wash-down friendly. Non-porous surface options for hospital supply routes, kitchens and food areas.

    • Factory-direct customization. Leaf size, glazing, bumpers and finishes tailored per opening — OEM/ODM, FOB/CIF worldwide.

    Key Features & Advantages

    Smooth double-acting swing. Opens with a light push from either direction and self-closes smoothly via heavy-duty gravity hinges — no handles needed, ideal when hands are full or gloved.

    High impact resistance. Reinforced composite leaf absorbs continuous impacts from hand trucks, carts and motorized equipment; bumper strips and spring bumpers absorb the worst hits at frame and leaf edges.

    Hygienic and easy to clean. Non-porous ABS, polyethylene or stainless faces wash down quickly and tolerate chemical sanitization in hospital supply routes and cleanroom corridors.

    Clear two-way visibility. Scratch-resistant, shatterproof vision windows prevent corridor collisions where pedestrians and carts share space.

    Environmental & dust barrier. Flexible perimeter seals on top, bottom and vertical edges block drafts, dust migration and energy loss between zones.

    Traffic Environment Guide

    EnvironmentRecommended build
    Hospital service corridors & linen routesStainless or ABS faces, large vision panels, hygienic seals
    Commercial kitchens & restaurantsABS/PE faces, bumper strips, wash-down hardware
    Supermarkets & stockroomsHigh-impact ABS, full-width polycarbonate windows
    Cold-chain & food processingInsulated leaf option, food-safe surface, draft seals
    Warehouses & loading zonesHeavy-duty steel-faced leaf, reinforced bumper protection

    Technical Specifications

    ParameterSpecification
    Door typeDouble-acting impact traffic door (single / double leaf)
    Door leaf thickness20–40 mm heavy-duty impact-resistant composite
    Surface materialHigh-impact ABS / polyethylene / 304 stainless steel / galvanized steel
    Hinge systemTop-and-bottom heavy-duty gravity hinges with V-cam mechanisms
    Vision windowClear acrylic / shatterproof polycarbonate safety glass
    Perimeter sealsFlexible rubber draft seals (top, bottom, vertical edges)
    Optional accessoriesStainless kick plates, bumper strips, spring bumpers

    Ideal Applications

    Hospitals: service corridors, kitchen passages, linen handling zones, sterile supply storage. Commercial & retail: supermarket backrooms, stockroom entries, restaurant kitchens. Logistics & warehousing: high-frequency traffic zones, loading bay access, cold-chain buffers. Food processing & industry: dust-controlled areas and clean manufacturing partitions.

    Customization & OEM/ODM Supply

    We offer full OEM/ODM customization to your opening dimensions (width × height), traffic density and hardware requirements — including CAD drawings, specification sheets and factory-direct pricing. Contact our technical team for a quotation.

    FAQ

    Q: How do gravity hinges self-close?
    A: Offset pivot geometry converts the leaf's weight into closing torque through a V-cam, returning the door to center from either direction — no springs or closers to maintain.

    Q: Can the doors be insulated for temperature zones?
    A: Yes — insulated leaf builds are available for cold-chain buffers and kitchen-to-dining transitions.

    Q: What face material should we pick for a hospital kitchen?
    A: 304 stainless for maximum wash-down durability, or high-impact ABS where cost matters — both tolerate sanitizing chemicals.

    Q: Do the windows comply with food-area rules?
    A: Polycarbonate/acrylic glazing is shatterproof and smooth — suitable for food-handling zones; confirm local code with your consultant.

    Q: Double leaf or single?
    A: Double leaf suits pallet-cart widths; single leaf is fine for pedestrian-dominant routes. Send opening sizes and traffic types — we'll specify.

Previous:

Next:

Product Inquiry

Please leave your message, we will contact you quickly after receiving it, thank you for your support!

Double-Acting Traffic Doors
  • What kind of product do you need?
  • What's your budget?
  • What other information do you need to know?

Technical Knowledge Base

Q

What is the main difference between EN 1634 and GB 12955 steel fire door standards?


A

EN 1634-1 is the European fire resistance test standard evaluating fire integrity (E) and thermal insulation (EI), with ratings classified as 30, 60, 90, or 120 minutes. GB 12955-2024 is the Chinese national fire door standard under which TCR steel fire doors are type-tested (ratings A0.5, A1.0, A1.5, A2.0) by the Shanghai Fire Research Institute.
Testing Method: EN 1634-1 evaluates fire integrity (E) and thermal insulation (EI) parameters; GB 12955 type-testing covers fire resistance and smoke tightness per the China national certification scheme.
Fire Ratings: EN classifications are 30, 60, 90, or 120 minutes; GB 12955 ratings correspond to A0.5, A1.0, A1.5, and A2.0 respectively.
Regional Usage: Select CE-marked doors with EN 1634-1-aligned test evidence for European and British-standard-aligned projects; GB 12955 type-test reports are provided as standard factory evidence for international procurement.

Q

How long can commercial steel fire doors withstand direct high temperatures?


A

Commercial steel fire doors are engineered to withstand direct high-temperature fire exposure from 20 minutes up to 180 minutes (3 hours), depending on the internal core material, gauge of galvanized steel, and certified testing standard.Fire RatingCore TypeTypical Commercial Applications60 Minutes (1 Hour)Honeycomb / Mineral WoolOffice corridors, residential stairwells, hotel rooms90 Minutes (1.5 Hours)Mineral Wool / PerliteHospital corridors, cleanrooms, commercial utility rooms120–180 Minutes (2–3 Hours)High-Density Mineral WoolIndustrial warehouses, transformer rooms, high-risk fire zones
